Heavy Duty Custom Slewing Bearing for Construction Mining Wind Power Machinery | OEM Standard & Non-standard | Factory Direct

Brand Name:	OEM, neutral/HRB/LYC/ZWZ/NSK/SKF/NTN/KOYO/FAG
Model Number:	120.25.500/120.25.560/120.25.630/120.25.710/120.28.800/120.28.900/120.28.1000/120.28.1120/120.32.1250/120.32.1400/120.32.1600/120.32.1600.03K/120.32.1800/120.40.2000/120.40.2240/120.40.2500/120.40.2800/120.50.3150/120.50.3550/120.50.4000/120.50.4500
MOQ:	1(negotiation)
Price:	negotiation
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	50,000pcs/month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Product Type:

1. Single Row Four-Point Contact Ball Slewing Bearing2. Double Row Angular Contact Ball Slewing Bearing3. Single Row Cross Roller Slewing Bearing4. Three-Row Cylindrical Roller Slewing Bearing

Material:

High-Carbon Chromium Steel

Diameter Range:

100mm - 15,000mm (Customizable; Large-sized Bearings Can Be Segmented For Transportation)

Precision Grade:

P0, P6, P5 (Optional); Surface Roughness: Ra ≤ 0.2μm; Axial Clearance: 0.02-0.05mm (Adjustable)

Customization:

Lubrication:

Grease / Oil

Packing:

Customer Requirement

Packaging Details:

sea worthy standard

Product Description

Product Description:

This is a versatile, high-performance slewing bearing designed to meet the diverse needs of industrial buyers across different markets. It is suitable for standard applications as well as customized requirements.

Market Adaptability & Key Applications:

This product serves multiple sectors, making it an ideal choice for various types of buyers:

Renewable Energy: Wind turbine yaw/pitch bearings and solar tracking systems.
Construction Machinery: Cranes, excavators, concrete pump trucks, and tower cranes.
Mining Equipment: Excavators, stackers, reclaimers, and conveying equipment.
Industrial Machinery: Machine tools, robotics, and automation equipment.
Agriculture & Transport: Rotary tillers, irrigation systems, and light rail repair.

Product Specifications:

Rolling Elements: Steel balls or rollers (as required).
Gear Type: Internal gear, external gear, or gearless.
Design Type: Single-row four-point contact ball, cross roller, three-row roller, or thin-section.
Size Range: 100mm to 5000mm.
Precision Grades: P0, P5, P6 optional.

Why Choose This Product:

Cost-Effective Alternative: Comparable performance to leading European brands at a significantly lower price (saving 30-50% on procurement costs).
Flexible Procurement:
- No minimum order quantity (MOQ) for common sizes.
- Mixed orders (multiple specifications in one batch) accepted.
- Small trial orders welcome.
Customization: Non-standard sizes and special designs are available. Customization lead time is 30-45 days.

Fast Delivery:

Direct shipping from factory via multiple ports for quick delivery to the region.

Current bearing designation	Dimensions(mm)			weigh
Current bearing designation	d	D	T	(kg)
Type120
XU120222	140	300	36
120.25.500	398	602	75	8O
120.25.560	458	662	75	90
120.25.630	528	732	75	100
120.25.710	608	812	75	110
120.28.800	678	922	82	170
120.28.900	778	1022	82	190
120.28.1000	878	1122	82	210
120.28.1120	998	1242	82	230
120.32.1250	1110	1390	91	350
120.32.1400	1260	1540	91	400
120.32.1600	1460	1740	91	400
120.32.1600.03K	1460	1740	100	429
120.32.1800	1660	1940	91	500
120.40.2000	1825	2178	112	900
120.40.2240	2065	2418	112	1000
120.40.2500	2325	2678	112	1100
120.40.2800	2625	2978	112	1250
120.50.3150	2922	3376	134	2150
120.50.3550	3322	3776	134	2470
120.50.4000	3772	4226	134	2800
120.50.4500	4272	4726	134	3100
